The BC Designs Victrion Bath Shower Mixer with Levers combines elegance with excellent functionality. It can be mounted either on the rim of the bath or mounted on our solid brass freestanding legs when there are no tap holes in your bath. The classic handset and spout give dual use. Both Exposed and Domed collars are provided as standard for you to install in whichever way you prefer. All Victrion Brassware is available in six special finishes.

• Classic timeless design
• Luxury white lever handles

• Suitable for low pressure systems
• Ceramic disc technology for long life and smooth operation
• High quality brass internals
• Includes shower kit
• Freestanding pipe sleeves sold separately

TECHNICAL Specifications

• Product Weight: 5kg
• Product Depth: 155 mm
• Product Height: 320 mm
• Product Width: 350 mm
• Tap Spout Projection: 121 mm
• Cartridge Included: Yes
• Control Type: Manual
• Flow Rate 0.2Bar 1/m: 10.6
• Flow Rate 0.5Bar l/m: 28.6
• Flow Rate 1Bar l/m: 41.4
• Flow Rate 2Bar l/m: 59
• Flow Rate 3Bar l/m: 72.8
• Handset Included: Yes
• Height Of Spout: 62 mm
• Mount Type: Deck
• No. Of Handles: 3
• Operating Pressure: 0.2 Bar
• Pipe Centres: 90-300
• Pipe Size: 22 mm (3/4" bsp)
