Nuie Windon Wall Mounted 2 Tap Hole Basin Mixer With Plate - Brushed Gun Metal
Stunning contemporary angular design with a striking brushed pewter finish. Ceramic disc technology provides smooth operation and long life. Excellent flow rates even at low pressure. WRAS approved. Height: 70 mm Weight: 2.04 kg Width: 180 mm Depth: 199 mm Material: Brass,Plastic Waste: No Mount Type: Wall Hung Handle Type: Lever/Square Minimum Operating Pressure (Bar): 0.2 Bar Valve/Cartirdge Type: Single Lever Cartridge WRAS Approved: Yes WRAS Approval Number: 2206032 TMV2 Approved: No TMV3 Approved: No Flow Rate at 0.1 Bar (L/min): 2.8000 Flow Rate at 0.5 Bar (L/min): 7.1000 Flow Rate at 1 Bar (L/min): 10.4000 Flow Rate at 2 Bar (L/min): 15.0000 Flow Rate at 3 Bar (L/min): 18.5000 Tap Holes Required: 1 Tap Spout Projection: 180.0000 mm Pipe Centres: 100 Manufacture Guarantee: 3 Years Guarantee Details: During installation extra care must be taken to avoid damaging the fittings. We provide Manufacture Guarantee against faulty workmanship or materials (excluding serviceable parts), providing they have been installed, cared for and used in accordance with our instructions.
Technical Specification
$73.65
Original: $210.42
-65%Nuie Windon Wall Mounted 2 Tap Hole Basin Mixer With Plate - Brushed Gun Metal—
$210.42
$73.65Product Information
Product Information
Shipping & Returns
Shipping & Returns
Description
Stunning contemporary angular design with a striking brushed pewter finish. Ceramic disc technology provides smooth operation and long life. Excellent flow rates even at low pressure. WRAS approved. Height: 70 mm Weight: 2.04 kg Width: 180 mm Depth: 199 mm Material: Brass,Plastic Waste: No Mount Type: Wall Hung Handle Type: Lever/Square Minimum Operating Pressure (Bar): 0.2 Bar Valve/Cartirdge Type: Single Lever Cartridge WRAS Approved: Yes WRAS Approval Number: 2206032 TMV2 Approved: No TMV3 Approved: No Flow Rate at 0.1 Bar (L/min): 2.8000 Flow Rate at 0.5 Bar (L/min): 7.1000 Flow Rate at 1 Bar (L/min): 10.4000 Flow Rate at 2 Bar (L/min): 15.0000 Flow Rate at 3 Bar (L/min): 18.5000 Tap Holes Required: 1 Tap Spout Projection: 180.0000 mm Pipe Centres: 100 Manufacture Guarantee: 3 Years Guarantee Details: During installation extra care must be taken to avoid damaging the fittings. We provide Manufacture Guarantee against faulty workmanship or materials (excluding serviceable parts), providing they have been installed, cared for and used in accordance with our instructions.
