This Hudson Reed basin mixer brings coordinated bathroom solutions to the basin area with a polished, traditional appearance. Equipped with solid brass body for long-lasting, dependable use. Well suited to main bathrooms, en-suites, and cloakrooms. Built for lasting good looks and everyday reliability.

• Traditional design
• Solid brass construction
• Brushed Pewter finish
• Wall-mounted basin mixer
• Single lever handle operation
• Requires 3 tap holes
• Waste sold separately
• Available in a range of finishes
• 3-year manufacturer's guarantee

Technical Specification

Height: 55 mm

Weight: 1.7 kg

Width:

Depth: 180 mm

Length:

Material: Brass

Waste: No

Mount Type: Wall Hung

Handle Type: Lever

Minimum Operating Pressure (Bar): 0.1

Valve/Cartridge Type: 1/4 Turn Ceramic Disc

WRAS Approved: No

TMV2 Approved: No

TMV3 Approved: No

Flow Rate at 0.1 Bar (L/min): 6.4

Flow Rate at 0.5 Bar (L/min): 16.2

Flow Rate at 1 Bar (L/min): 23.4

Flow Rate at 2 Bar (L/min): 33.5

Flow Rate at 3 Bar (L/min): 41

Tap Holes Required: 3

Tap Spout Projection: 180

Manufacture Guarantee: 3 Years

Guarantee Details: During installation extra care must be taken to avoid damaging the fittings. We provide Manufacture Guarantee against faulty workmanship or materials (excluding serviceable parts), providing they have been installed, cared for and used in accordance with our instructions.
